Starter 0986018910
Click to zoom
BOSCH

Starter 0986018910

SKU: 0986018910

Ask us for a price

Write to us with the part number and your country. We answer with the price and the delivery cost.

Request a QuoteAsk a Question

Product Details

Brand
BOSCH
SKU / MPN
0986018910
Bore diameter (mm)
10
Bore (mm)
10
Clamp
50
Connecting angle (degree)
39
Fastening hole angle measurement (degree)
39
Flange diameter (mm)
76.2
Flange (mm)
76.2
Jaw opening angle measurement (degree)
63
Length (mm)
240
Mounting angle (degrees)
39
Mounting bore angle measurement (degree)
39
Number of mounting bores
1
Number of teeth
9
Number of thread bores
2
Number of threaded holes
2
Pinion rest position (mm)
-0.7
Position degree
rechts
Rated power (kW)
2.2
Rotation direction
Clockwise rotation
Starter type
Self-supporting
Thread size
M10
Thread size 1
M10x1.5
Thread size 2
M10x1.5
Voltage (v)
12
Terminal
30.50
Direction of rotation
Clockwise
EU VAT-registered company
Shipped from the EU

OE / Cross-Reference Numbers

This part replaces or is compatible with these OE (Original Equipment) numbers. Search any of these numbers to find this product.

1891000110925238036468602355860281894968823065856736050272098601891331651433108168EA738056-0018EA738056001CS1271DRS8910LRS01638LRS1638

Compatible Vehicles (19)

This part fits the following vehicles. Always verify with your vehicle's VIN or OE number before ordering.

MakeModelYears
VOLVOS60 I 2.4 D2001 - 2010
VOLVOS60 I 2.4 D2005 - 2009
VOLVOS60 I 2.4 D2005 - 2010
VOLVOS60 I D52001 - 2010
VOLVOS60 I D52005 - 2010
VOLVOS80 I 2.4 D2001 - 2006
VOLVOS80 I D52001 - 2006
VOLVOV70 II 2.4 D2001 - 2007
VOLVOV70 II 2.4 D2005 - 2007
VOLVOV70 II D52001 - 2007
VOLVOV70 II D52005 - 2007
VOLVOV70 II D5 AWD2003 - 2007
VOLVOV70 II D5 AWD2005 - 2007
VOLVOXC70 I Cross Country D5 AWD2005 - 2007
VOLVOXC70 I Cross Country D5 XC AWD2002 - 2007
VOLVOXC90 I D3 / D52009 - present
VOLVOXC90 I D5 AWD2002 - present
VOLVOXC90 I D5 AWD2006 - present
VOLVOXC90 I D5 AWD2011 - present
